Apogee 16X16S2 Symphony IO Mk II 16x16 Dante Audio Interface System
Apogee Symphony IO Mk II 16x16 Dante Audio Interface System The Symphony IO Mk II 16x16 Dante System delivers flagship grade AD/DA conversion with flexible modular I/O and networked audio via Dante. It is built for large scale recording broadcast immersive audio...
PRODUCT DETAILS
Everything you need to know.
Apogee Symphony IO Mk II 16x16 Dante Audio Interface System
The Symphony IO Mk II 16x16 Dante System delivers flagship grade AD/DA conversion with flexible modular I/O and networked audio via Dante. It is built for large scale recording broadcast immersive audio post production and scoring studios.
This unit includes 16 balanced analog inputs and 16 outputs with additional digital I/O support via S PDIF. The touch display front panel offers precision control and visual feedback. It supports sample rates up to 192 kHz and provides high dynamic range with ultra low distortion.
Designed for Mac and Windows users this rackmount audio interface provides versatile connectivity and the power required for modern multichannel production. Its modular design also allows future expansion with additional I/O cards.
Key Features
- 16 analog inputs and 16 analog outputs on balanced DB 25 connectors
- Dante network connectivity with dual ports for redundancy
- S PDIF coaxial I/O for digital integration
- Supports sample rates up to 192 kHz 24 bit
- Front panel touchscreen for easy monitoring and control
- Modular design for expandability with additional I/O cards
Technical Specifications
- Analog Inputs 16 x DB 25 balanced
- Analog Outputs 16 x DB 25 balanced
- Digital I/O S PDIF coaxial
- Sample Rates 44.1 to 192 kHz 24 bit
- Dynamic Range up to 131 dB depending on module configuration
- THD N approximately 116 dB A D 119 dB D A
- Rack Size 2U with rack ears included
- Power Supply Universal AC 90 240 V 50 60 Hz
