Kramer Aspen 3232HD‑3G 32x32 3G‑SDI Matrix Switcher

Kramer Aspen 3232HD‑3G 32×32 3G‑SDI Matrix Switcher

The Aspen 3232HD‑3G is a compact 2‑RU SDI matrix router supporting 32 input/output channels across SD‑SDI, HD‑SDI, and 3G‑SDI formats. It provides reliable routing for broadcast, AV, and production environments.

Featuring Kramer’s Equalization & Re‑clocking technology, it ensures clean signal transmission up to 155 m at 3G speeds. Control options include front-panel buttons, Ethernet/web interface, and RS‑232/422, with support for presets and remote automation.

Key Features

• I/O: 32 × 3G‑SDI BNC ports
• Formats: SD-SDI, HD-SDI, 3G-SDI, DVB-ASI
• Max Data Rate: 2.97 Gbps
• Equalization & Re-clocking: Extends cable runs—up to 155 m at 3G
• Genlock: Loop-through analog input, clean switching
• Latency: <1 frame
• Control: Front-panel, Ethernet/web GUI, RS‑232/422, presets/salvos
• Power: 100-240VAC to 12VDC, ~18 W consumption
• Operating Range: 0-40 °C, non-condensing
• Warranty: 7 years

Technical Specifications

• Dimensions (W×D×H): 19″ × 2.5″ × 3.5″ (48.3 × 6.4 × 8.9 cm)
• Net Weight: 4 lb (1.8 kg)
• Power: External 12 V DC, ~18 W
• Warranty: 7 years (parts & labor)
• Compliance: SMPTE standards, DVB-ASI
• Connectivity: BNC, RJ‑45, DB‑9

What's Included

• 1 × Kramer Aspen 3232HD‑3G unit
• 1 × External 12 V DC power supply
• Rack-mount ears
